SPB8100 시리즈 지능형 압력 트랜스미터

SPB81 series intelligent pressure transmitter adopts 16-bit single-chip microcomputer. Its powerful functions and high-speed computing ability ensure the basic excellent performance of the transmitter. The entire design framework focuses on reliability, stability, high precision and intelligence to meet the increasing demands Requirements for industrial field applications. The software adopts digital signal processing technology, which makes it have excellent anti-interference ability and zero point stability, and has zero point automatic stable tracking ability (ZSC) and temperature automatic compensation ability (TSC). Good human-computer interaction can be guaranteed. The digital meter can display various pressures, liquid level heights and percentages, and key operation can easily complete basic parameter settings such as zero point migration, range setting, and damping setting without a standard pressure source, which greatly facilitates the scene. Debugging and user usage.

• Accuracy: 0.2%F·S , 0.5%F·S
• Measuring range: -0.1...0bar to -1...0bar 0...0.1bar to 0...600bar to -1...25bar relative 0...1bar to 0...35bar absolute
• Output: 4...20mADC
• Linearity: superior to 0.2% F·S
• Ambient temp: -20...85℃
• Temperature drift: Superior to ±0.2%F·S/°C
• Stability: superior to 0.2%F·S for 1 year
• Power supply: 12...36VDC
• Load resistance: 0~600Ω
• Proof pressure: 150%F·S
• Storage temp: -40...125℃
• Can modify the range of transmitter with screen
